WORKING PARAMETERS LOGGING
The devices are monitoring the operating parameters installed on Drilling Rigs, providing measuring, indicating and recording parameters. The Electronic equipment for measuring, indicating and recording the Hook Load and the daily activities is a device that provides real-time evolution for operator regarding limit the load to the maximum allowable.
Recording the hook load offer indirect information regarding the type of the drilling operation carried, duration and parameters on which drilling operations was executed.
Equipment monitors the following parameters:
- hook load
- weight on bit
- fuel consumption
- temperature for cooling brake system
Technical features
· Supply voltage: 24 Vdc
· Working temperature: -29º to + 70º C
· Read rate: 1 ms (or freely configurable)
· The rate of memory: 0.1s, 1s; 2s; 5s; 30s; ...... 10 min.
· Time scale (abscissa) : freely configurable between 1 min and 24h
· Alarm Function : Settable for the load
· Operating System: Linux Embedded
· Load range : 0 ÷ 40tf (configured to provide 20mA for load of 60tf)
· Analog indicator scale: 0 ÷ 44tf
· Load Measuring Accuracy: 0.5%
· Fuel Consumption Measuring Accuracy : 1%
· ATEX explosion protection degree: - II1GExdIIBT5
· Resistance at vibration: 5 g
· Resistance to shock: 30 g
· Normal degree of protection: IP66
· Weight of Indication Panel : 28.5 Kg
· Dimensions of Indication Panel: 330 x 430 x 230 mm
Pentru mai multe detalii citeste fisierul atasat -
